24 ST8001+ Smartpilot Controller Operating Guide
User Calibration pages
AutoTack angle (SAILBOAT only)
This calibration setting has no effect on ST8001 systems
Gybe inhibit (SAILBOAT only)
This calibration setting has no effect on ST8001 systems
Wind selection (SAILBOAT only)
This screen determines whether the boat steers to apparent or true wind in
Wind Vane mode.
WindTrim (SAILBOAT only)
WindTrim controls how quickly the SmartPilot responds to changes in the
wind direction. Higher wind trim settings will result in a system that is more
responsive to wind changes.
Response level
This sets the default SmartPilot response level setting. The response level
controls the relationship between course keeping accuracy and the amount of
helm/drive activity. You can make temporary changes to response during
normal operation (see page 8).
Options
WIND APP (Default) SmartPilot steers to apparent wind angle
WIND TRUE SmartPilot steers to true wind angle
Screen Text Options
WIND TRIM Range = 1 to 9
1 to 3 - Least responsive to wind changes (less system activ-
ity)
4 to 6 - Moderate response to wind changes
7 to 9 - Most responsive to wind changes (more system activ-
ity)
