Ricoh 6513 User Manual
Page 217
Troubleshooting
202
6
E
Align the arrow mark on the new refill with that on the cartridge and push
the new refill into the cartridge until a click is heard.
F
Pull the ribbon out of the cartridge.
G
Place the cartridge in the staple unit.
H
Turn the cartridge backward until a click is heard.
I
Return the R3 holder back to its original position.
J
Close the sorter stapler front cover.
Cat2-5_FM.book Page 202 Tuesday, February 20, 2001 9:27 AM
