60
Specifications
Digital Audio Workstation: SONAR V-STUDIO 100
Audio Interface, Mixer
Number of Input Channels 8
AD/DA Conversion
Sample Rate: 44.1/48.0/96.0 kHz
Signal Processing: 24 bits
DSP processing
Compressor: Input Jacks 1–6
Equalizer: Input Jacks 1–6
Reverb: Input Jacks 1–6 (Echo/Room/Small Hall/Large Hall)
Internal: 40 bits
Number of USB Audio Record/
Playback Channels Record: 10 channels
Playback: 6 channels (Full duplex)
Frequency Response
96.0 kHz: 20 Hz to 40 kHz (+0/-3 dB)
48.0 kHz: 20 Hz to 22 kHz (+0/-3 dB)
44.1 kHz: 20 Hz to 20 kHz (+0/-3 dB)
Residual Noise Level
(IHF-A, typ.) - 81 dBu
(MAIN MIX knob = U, CHANNEL VOLUME knobs = U)
Dynamic Range
AD block: Input Jacks 1–2: 104 dB typ. (GAIN: min.)
Input Jacks 3–6: 100 dB typ.
DA block: Output Jack 1–2: 112 dB typ.
Output Jack 3–6: 106 dB typ.
Nominal Input Level:
Mic Input Jacks 1–2: -60 to -16 dBu
Input Jacks 1–2: -40 to +4 dBu
Input Jacks 3–4: +4 dBu
Input Jacks 5–6: -10 dBu
* Maximum input level: Nominal input level + 18 dB
Input Impedance
Mic Input Jacks 1–2: 1.5 k ohms
Input Jacks 1–4: 15 k ohms
Input Jacks 1 (Hi-Z): 500 k ohms
Input Jacks 5–6: 18 k ohms
Nominal Output Level
Output Jack 1–4: +4 dBu
Output Jack 5–6: -10 dBu
* Maximum output level : Nominal Output Level + 18 dB
Output Impedance
Output Jack 1–4: 2 k ohms
Output Jack 5–6: 1 k ohms
Recommended Load
Impedance
10 k ohms or greater
Connectors
Mic Input Jacks 1–2: XLR type (balanced/phantom power +48 V)
Output Jacks 1–4: 1/4 inch TRS phone type (balanced)
Output Jacks 5–6: RCA pin type
MIDI Connectors (Input/Output)
Digital Input Connector:
Coaxial type
USB Connector (B type)
Headphones Jack:
Stereo 1/4 inch phone type
