4.2.5 A/D converter
__CreateADC
Synopsis
Boolean __CreateADC(unsigned long data1, unsigned int data2, unsigned int
data3, void* func)
data1
Setup data 1
data2
Number of analog input pins used by A/D converter
data3
Setup data 3
func
Callback function pointer
(Specify 0 if no callback functions are set.)
Description
Sets the A/D converter to specified mode and operating condition.
[data1]
For data1, the following definition values can be set. To set multiple definition values at
the same time, use the symbol “|” to separate each specified value. Note, however,
that multiple analog input pin symbols cannot be specified at the same time.
RAPI_ONE_SHOT
Selects one-shot mode.
RAPI_REPEAT
Selects repeat mode.
RAPI_SINGLE_SWEEP
Selects single sweep mode.
RAPI_REPEAT_SWEEP0
Selects repeat sweep mode 0.
RAPI_REPEAT_SWEEP1
Selects repeat sweep mode 1.
RAPI_AN0 Uses
AN
0
pin for the analog input pin.
RAPI_AN1 Uses
AN
1
pin for the analog input pin.
RAPI_AN2 Uses
AN
2
pin for the analog input pin.
RAPI_AN3 Uses
AN
3
pin for the analog input pin.
RAPI_AN4 Uses
AN
4
pin for the analog input pin.
RAPI_AN5 Uses
AN
5
pin for the analog input pin.
RAPI_AN6 Uses
AN
6
pin for the analog input pin.
RAPI_AN7 Uses
AN
7
pin for the analog input pin.
RAPI_AN00 Uses
AN
00
pin for the analog input pin.
RAPI_AN01 Uses
AN
01
pin for the analog input pin.
RAPI_AN02 Uses
AN
02
pin for the analog input pin.
RAPI_AN03 Uses
AN
03
pin for the analog input pin.
RAPI_AN04 Uses
AN
04
pin for the analog input pin.
RAPI_AN05 Uses
AN
05
pin for the analog input pin.
RAPI_AN06 Uses
AN
06
pin for the analog input pin.
RAPI_AN07 Uses
AN
07
pin for the analog input pin.
RAPI_AN20 Uses
AN
20
pin for the analog input pin.
RAPI_AN21 Uses
AN
21
pin for the analog input pin.
RAPI_AN22 Uses
AN
22
pin for the analog input pin.
RAPI_AN23 Uses
AN
23
pin for the analog input pin.
RAPI_AN24 Uses
AN
24
pin for the analog input pin.
RAPI_AN25 Uses
AN
25
pin for the analog input pin.
RAPI_AN26 Uses
AN
26
pin for the analog input pin.
