[data4]
Specify 0.
Return value If the timer specification is incorrect, RAPI_FALSE is returned; otherwise, RAPI_TRUE
is returned.
Functionality Timer (pulse width measurement mode)
Reference __EnablePulseWidthMeasurementMode , __DestroyPulseWidthMeasurementMode ,
__GetPulseWidthMeasurementMode
Remark • If an undefined value is specified in the first argument, operation of the API cannot
be guaranteed.
Program example
#include "rapi_timer_m16c_62p.h"
void TimerIntFunc( void ){}
void func( void )
{
/* Set up timer B4 as pulse width measurement mode */
__CreatePulseWidthMeasurementMode(
RAPI_TIMER_B4|RAPI_TIMER_ON|RAPI_RISING_FALLING|RAPI_F8,
5, 0, 0, TimerIntFunc);
}
