MIDI implementation chart

40

[Shoulder Synthesizer]

Date: March 2009

Model: AX-Synth

Version: 1.00

13. MIDI implementation chart

Function...

Transmitted

Recognized

Remarks

Basic
Channel

Default
Changed

1
1~16, Off

1
1~16

Memorized

Mode

Default
Message
Altered

Mode 3
Mono, Poly
*****

Mode 3
Mode 3, 4 (M= 1)
X

Note
Number

True Voice

0~127
*****

0~127
0~127

Velocity

Note ON
Note OFF

O
O

O
O

After
Touch

Key’s
Ch’s

X
O

O
O

Pitch Bend

O

O

Control
Change

0,32

1
5

6, 38

7

10
11
34
64
65
66
71
72
73
74
75
84
91
93

1~31, 33~95

100, 101

O

*1

O

*1

O

*1

O

*1

O

*1

O

*1

O

*1

O

*1

O

*1

O

*1

O

*1

O
O
O
O
O
O
O (Reverb)

*1

O (Chorus)

*1

O

*1

X

*1

O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
X
O

Bank Select
Modulation
Portamento Time
Data entry
Volume
Panpot
Expression
Breath type
Hold 1
Portamento SW
Sostenuto
Harm. Content (Reso)
Release Time
Attack Time
Brightness (Cutoff)
Sound Control
Portamento Control
Effect 1 Depth
Effect 3 Depth
D Beam
RPN LSB, MSB

Program
Change

True #

O
*****

O
O~127

Program no. 1~128

System Exclusive

O

O

System
Common

Song Position Pointer
Song Sel
Tune

X
X
X

X
X
X

System
Real Time

Clock
Commands

X
X

X
X

Aux
Messages

All Sounds Off
Local On/Off
All Notes Off
Active Sensing
Reset

X
X
X
O
X

*1

O
X
O (123~127)
O
X

Notes

*1 O X is selectable
*2 Recognized as M=1 even if M

1

Mode 1: OMNI ON, POLY
Mode 3: OMNI OFF, POLY

Mode 2: OMNI ON, MONO
Mode 4: OMNI OFF, MONO

O: Yes
X: No
