Other Information
44 Chapter 5
Back Panel
ANT. IN jack Receives an antenna or cable system signal when the VCR is attached using RF
coaxial cables.
AUDIO and VIDEO IN jacks Receives signals from another component (such as a VCR or
camcorder) when connected to these jacks. Use the INPUT button on the remote control to select
the Video Line Input when recording from these jacks.
AUDIO and VIDEO OUT jacks Sends signals from the VCR to another component (like a TV or
VCR), when connected to these jacks.
CH. 3/4 switch Determines the channel which the TV must be tuned to in order to see the
VCR’s picture. Not used when connecting the VCR to the TV using Audio/Video cables.
RF OUT jack Passes the VCR’s signal to the TV using the supplied RF coaxial cable.
CH
ANT. IN
OUT IN
AUDIO
VIDEO
3 4
RF OUT
