Chapter 4. Specifications
4.1 Specifications
Table 4.1 lists common specifications of the programming adapters, and Tables 4.2 and 4.3 list
individual specifications of each programming adapter.
Table 4.1 Common specifications
Table 4.2 Individual specifications (1/2)
Operating clock frequency
Description
4 MHz
(Supplied by the ceramic oscillator mounted on the
adapter)
Supplied from Vcc of the PROM programmer
Board to mount a programmable MCU
(IC socket for MCU mounted on it)
Interface board (buffer IC mounted)
(Connected by two rows of standard-pitch 18-pin
connectors and two rows of standard-pitch 16-pin
connectors to the upper and lower boards)
Board to connect to the PROM Programmer
(for M5M27C256 mode)
(Standard-pitch 28-pin pin-header mounted)
Board to connect to the PROM Programmer
(for M5M27C101 mode)
(Standard-pitch 32-pin pin-header mounted)
Item
Main unit
Board
configuration
Power supply
PCA4738D or PCA7402D
(28-pin connector)
PCA4738C or PCA7402B
(Interface unit)
PCA7438E or PCA7402E
(32-pin connector)
MCU
IC socket
PCA4738S-64A
MCU
IC socket
PCA4738F-64A
MCU
IC socket
PCA4738L-64A
Product name Item Description
MCU
IC socket
PCA4738S-42A
MCU
IC socket
PCA4738F-42A
38000 Series SDIP package
(42P4B, 42S1B) 3850, 3851 Group
42-pin SP/SS package
IC59-4206-G4 (made by Yamaichi Electronics Co., Ltd.)
38000 Series QFP package
(42P2R-A) 3850, 3851 Group
42-pin FP package
IC51-0422-393 (made by Yamaichi Electronics Co., Ltd.)
38000 Series SDIP package
(64P4B, 64S1B)
3800, 3802, 3810, 3811, 3812,
3880, 3888, 3890 Group
64-pin SP/SS package
264-1300-00 (made by Sumitomo 3M Limited)
38000 Series QFP package
(64P6N-A)
3800, 3802, 3810, 3811, 3812,
3880, 3888, 3890 Group
64-pin FP package
IC51-824.KS-8095 (made by Yamaichi Electronics Co., Ltd.)
38000 Series LCC package
(64D0)
3800, 3802, 3810, 3811, 3812,
3880, 3888, 3890 Group
64-pin FS package
IC51-0644-1329 (made by Yamaichi Electronics Co., Ltd.)
