and press the cord all the way down
into the cord groove on the bottom
of the base.

4. Position the mounting bracket with

the narrow end on top. Route the
short modular cord through the cen-
ter hole of the bracket, and insert
the two tabs at the top of the bracket
into the matching slots on the base’s
back, near the jacks.

5. Press the two tabs at the bottom of

the bracket into the matching slots
on the back of the base to lock the
bracket into place.

6. Plug the modular cord’s other end

into the wall plate’s modular phone
line jack.

7. Align the keyhole slots on the

bracket with the studs on the wall
plate, then slide the base downward
to secure it.

8. Plug the AC adapter into a standard

AC outlet.

9. For the best re-

ception, raise the
base’s antenna to
a vertical position.

illus -- label strain relief

Illus

illus -- show modular
cord already connected

Illus
