CTH2-S ERIES I NSTALLATION , O PERATION AND S ERVICE M ANUAL
2
FIGURE 2: Side and Back Panel Label Placement
Clearances to Combustibles Label
Control Side Panel
Control Side Panel (Inside) Wiring Label
Description Part Number
Clearances to Combustibles Label 91013415
Wiring Label 91013300
Thermostat Connection Label 91037902
Vent Length Label 91039500
Lighting Instruction Plate Label 91029602
Lighting Instruction Plate Label
Thermostat
Connection
Label
Vent Length Label
Back Panel
