CTH2-S ERIES I NSTALLATION , O PERATION AND S ERVICE M ANUAL
46
Tubes Make sure there are no cracks.
Make sure tubes are connected and suspended securely.
See Page 12, Section 6 .
Make sure there is no sagging, bending or distortion.
Clean or replace as required.
Gas Line Check for gas leaks. See Page 39, Section 9.
Burner Observation
Window Make sure it is clean and free of cracks or holes.
Clean and replace as required.
Blower Scroll, Wheel and
Motor
Compressed air or a vacuum cleaner may be used to clean dust and dirt.
Burner Cup and Orifice Clear of obstructions (even spider webs will cause problems).
Carefully remove any dust and debris from the burner.
Hot-Surface Igniter Replace if cracked or broken.
Thermostat There should be no exposed wire or damage to the thermostat.
See Page 41, Section 10 .
Suspension Points Make sure the heater is hanging securely. Look for signs of wear on the chain
or ceiling. See Page 13, Figure 14.
Decorative and Protective
Grille (optional) The grille must be securely attached.
Check that the side reflector extensions are installed correctly and secured in
place if necessary. (Decorative grille only.)
See Page 30, Section 7.5 and Page 32, Section 7.6.
Make sure shield is installed correctly and secured in place if necessary.
(Decorative grille only.) See Page 31, Section 7.5.2.
Lower Clearance Shield
(optional) The lower shield must be securely attached. Inspect shield support straps
and lower clearance shield anchor points. See Page 30, Section 7.4.
Make sure shield is installed correctly and secured in place if necessary.
See Page 30, Section 7.4 .
Wall Tag If wall tag is present, make sure it is legible and accurate. Please contact
Roberts-Gordon LLC or your ROBERTS GORDON
® independent distributor,
if you need a wall tag. See Page 3, Section 2.1.
