7.2
Crystal Series LCD
Display Dimensions
Figure 7-1 and Figure 7-2 show the Crystal Series LCD Display dimensions (all dimensions
are in inches).
Figure 7-1. CX-40HD Dimensions
4.72
38.84
34.91
Fr
ont
s
ide view
To
p
s
ide view
Right
s
ide view
Rear
s
ide view
Cable Acce
ss
Ar
ea
Active Area
W
a
ll Mount
S
cr
ew
6-M6 T
a
p
1.69
3.90
9.84
19.65
23.58
27.88
5.42
7.87
7.87
23.62
22.72
1.14
3.15
