35
Repair Parts
Parts List for RIDGID 15" Drill Press
Model No. DP15501
Figure 1
Always order by Part Number - Not by Key Number
* Standard hardware item - may be purchased locally.
1
4
6
11
15
19
17
18
2
4
4
4
7
21
22
16
10
13
5
3
20
8
9
9
10
13
14
14
12
Key
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
829775
828814
828812
828932
828813
828811
816439-4
828919
817358-1
820241-5
Guard Upper
Link - Rear
Clamp - Rear Link
* Screw Pan Hd
M5.5 x 1.8-12
Link - Front
Clamp - Front Link
Belt Poly V 27"
Pulley Asm - Idler
* Screw Rd Hd Wash
M6 x 1.0
* Lockwasher Ext M6
Key
No.
Part No. Description
11
12
13
14
15
16
17
18
19
20
21
22
828818
828816
817537
817530
817536
821734
828849
821742
829688
816439-5
828820
828821 Pulley Asm - Motor
Guard Lower
Ring Retaining
Bearing Ball 20 mm
Spacer
Insert Pulley
Pulley Spindle
Nut Pulley
Cap Spindle
Belt Poly V 25"
Latch
Spring Latch
