C34 Gas Stove
Venting Arrangements - Horizontal
Terminations
This diagram shows all allowable combinations of vertical runs with
horizontal terminations, using one 90° elbow (two 45º
elbows equal
one 90° elbow).
The lightly shaded area,
6 8 2 0 4 10
0
2
4
6
40
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
12
, in the diagram shows allowable
combinations with Vent Restrictor in position “C” (Center), refer to
page 113.
The darker shaded area,
6 8 2 0 4 10
0
2
4
6
40
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
12
, in the diagram shows allowable
combinations with Vent Restrictor in position “L” (Left), refer to page
113.
• Maintain clearances to combustibles.
• Horizontal vent must be supported every 3 feet.
• Firestops are required at each floor level and whenever
passing through a wall.
A vent guard may be required as per local codes, refer to page 11 for
“Exterior Vent Termination Locations”.
Note: FPI Direct Vent System (Flex) is only approved for horizontal
terminations.
Maximum:
30
ft.
(9.1m)
Minimum
6
ft.(1.8m)
Max. 5 ft. (1.5m)
Maximum:
13
ft.
(4m)
0
2
4
6
8
10
12
14
16
18
20
22
24
V
ertical
Height
(Feet)
6 8
Horizontal (Feet)
2 0 4 10 12 14
Minimum
5
ft.
(1.5m)
Maximum:
8
’6
”
(2.6m)
Vent Restrictor on posittion “C”
Vent Restrictor on posittion “L”
Horizontal Venting with Two (2) 90°
Elbows
Two 45° elbows = One 90° elbow
Option V H + H1 Maximum total pipe length, of all
sections, must not exceed 30 feet.
Total horizontal sections must not
exceed 8 feet.
Minimum of 1 foot between 90°
elbows is required.
A) 4’ Min. 6’ Max.
B) 5’ Min. 7’ Max.
C) 6’ Min. 8’ Max.
Vent Restrictor in position “C” (Center), refer to page 113.
