Chapter 1 Introduction MBE Family Installation and Operation Manual
1-10 Technical Specifications
Product configurations and software are saved in flash memory. Two versions of
the software are stored for redundancy.
1.4 Technical Specifications
LAN Interface Standard Conforms to Ethernet/IEEE 802.3
Type 10Base5 (AUI)
10Base2 (BNC) (Thin Coax)
10BaseT (UTP)
Connectors 10Base5: 15-pin D-type, female
10Base2: BNC female
10BaseT: RJ-45
LINK
Interface Interface/
Connectors
V.35*: 34-pin female
V.24/RS-232*: 25-pin D-type, female
X.21: 15-pin D-type, female (through adapter cable)
V.36/RS-422: 37-pin D-type, female (through adapter
cable)
RS-530: 25-pin D-type, female
4W: 5-screw terminal block
Basic Rate ISDN
("S" or "U" interface) – RJ-45
CSU/DSU: RJ-45
Note: *The interface can function as DTE or DCE.
Protocol Synchronous: HDLC-based
Asynchronous: Programmable UART
Data Rates V.24/RS-232 (Synchronous): up to 64 kbps
V.24/RS-232 (Asynchronous): 2.4 to 115.2 kbps
V.35, X.21, V.36/RS-422, RS-530: up to 1.5 Mbps
4W: 16 to 768 kbps (selectable, internal clock)
DDS: up to 56 kbps
Basic Rate ISDN: 56, 64, 112, 128 kbps
