52
Chapter 7 Reference
7-7. Preset Timing
The following table shows factory preset video timing (for analog signal only).
Attention
• Display position may be deviated depending on the PC connected, which may require screen adjustment using
Adjustment menu.
• If a signal other than those listed in the table is input, adjust the screen using the Adjustment menu. However,
screen display may still be incorrect even after the adjustment.
• When interlace signals are used, the screen cannot be displayed correctly even after screen adjustment using the
Adjustment menu.
Resolution
Applicable
signal
Frequency Polarity
Dot clock:
MHz
Horizontal:
kHz
Vertical:
Hz
Horizontal Vertical
720 × 400 VGA TEXT 28.32 31.47 70.09 Negative Positive
640 × 480 VGA 25.18 31.47 59.94 Negative Negative
800 × 600 VESA 40.00 37.88 60.32 Positive Positive
1024 × 768 VESA 65.00 48.36 60.00 Negative Negative
1280 × 960 VESA 108.00 60.00 60.00 Positive Positive
1280 ×1024 VESA 108.00 63.98 60.02 Positive Positive
1600 ×1200 VESA 161.99 75.00 60.00 Positive Positive
1680 ×1050 VESA CVT 146.25 65.29 59.95 Negative Positive
1920 ×1080 CEA-861 148.50 67.50 60.00 Positive Positive
1920 ×1200 VESA CVT RB 154.00 74.04 59.95 Positive Negative
