Eizo COLOR EDGE CG245W - Manual (Page 29)

29
Chapter 3 Setting Monitor
3-5. Setting Language [Language]
This function allows you to select a language for the adjustment menu or displaying message.
Selectable languages
English/German/French/Spanish/Italian/Swedish/Japanese /Simplified Chinese/Traditional Chinese
Procedure
1. Choose
.
2. Choose from the .
3. Choose a language with or .
4. Press to exit the adjustment.
3-6. Setting Range of Frequency [Signal Bandwidth]
Depending upon your operating environment, it may be necessary to set the frequency that corresponds
to your graphics board. If you install it for the first time or change environment, set the monitor.
NOTE
• Refer to the manual of the graphics board.
• These environment described below can be set regardless of whether or not the computer is running.
• Only digital input signals can be set up.
Procedure
1. Press
to turn off the monitor.
2. Press holding down at least 2 seconds to turn on the monitor.
The Optional Settings menu appears.
3. Choose from the menu, and press .
4. Select “Normal” or “Wide” with or , and press .
Use or to select (or just confirm) the frequency that corresponds to your graphics board.
Setting Horizontal scanning frequency
(kHz)
Vertical scanning frequency
(Hz)
Normal 26~78 59~61
Wide -1 26~78 23.75~63
Wide -2/-3 * 1 Used when inputting a special signal.
*1: Wide-2/3 cannot be selected when using DisplayPort.
5. Press
6. Select “Finish” with
or .
7. Press .
The Optional Settings menu is closed.
