2 Depending on your GBIC model, either grasp the extraction
tabs (
Figure 1 ) located on either side of the GBIC with your
thumb and forefinger, or lift the extractor handle ( Figure 1 )
attached to the GBIC.
3 Slide the GBIC out of the Gigabit Ethernet module slot.
4 If the GBIC does not slide easily from the module slot, use a
gentle side-to-side rocking motion while firmly pulling the
GBIC from the slot.
5 Dispose of the GBIC according to all national laws and
regulations.
GBIC specifications
Table 2 describes general GBIC specifications.
Note: If you are storing a GBIC, remember to place a
dust cover over the fiber optic bores.
Table 2 GBIC specifications
Specification Descriptions
Dimensions (H x W x D) 0.39 x 1.18 x 2.56 inches
(1 x 3 x 6.5 cm)
Connectors Multimode fiber optic: SC
Single-mode fiber optic: SC
