23
1000BASE-SX (LC Type)
The Model 1000BASE-SX SFP GBIC provides 1000BASE-SX
(850 nm, short wavelength, Gigabit Ethernet) connectivity using
LC duplex multimode fiber connectors.The Model 1000BASE-
SX SFP GBIC supports full-duplex operation only
.
Table 10 describes standards, connectors, cabling, and distance
for the Model 1000BASE-SX SFP GBIC.
Table 10 1000BASE-SX SFP GBIC specifications
Type Specifications
Standards Conformity to the following standards:
802.3z, 1000BASE-SX
Connectors Duplex LC fiber optic connector
Cabling 62.5 µm MMF optic cable
50 µm MMF optic cable
Distance 902 ft. (275 m) using 62.5 µm MMF optic
cable
1804 ft. (550 m) using 50 µm MMF optic cable
Wavelength 850 nm
Optical budget 7 dB
Laser Transmitter Characteristics
Minimum launch power -10 dBm
Maximum launch power -4 dBm
Receiver
Characteristics
Minimum receiver
sensitivity -17 dBm
