22
5 Dispose of the SFP GBIC according to all national laws and
regulations.
Small Form Factor Pluggable (SFP) GBIC
specifications
Table 9 describes general SFP GBIC specifications.
Standards, connectors, cabling, and distance
This section describes SFP GBIC standards, connectors, cabling,
and distance; and provides specifications for the following SFP
GBICs:
• “1000BASE-SX (LC Type)” on page 23
• “1000BASE-LX (LC Type)” on page 24
• “1000BASE-SX (MT-RJ Type)” on page 25
Note: If you are storing a SFP GBIC, remember to place
a dust cover over the fiber optic bores.
Table 9 Small Form Factor Pluggable (SFP) GBIC
specifications
Specification Descriptions
Dimensions (H x W x D) 0.53 x 0.33 x 2.22 inches
(13.4 x 8.5 x 56.4 mm)
Connectors Multimode fiber optic: LC or MT-RJ
Single-mode fiber optic: LC or MT-RJ
