25
1000BASE-SX (MT-RJ Type)
The Model 1000BASE-SX (MT-RJ Type) SFP GBIC provides
Gigabit Ethernet connectivity using MT-RJ multi-mode fiber
connectors.
Table 12 describes standards, connectors, cabling, and distance
for the Model 1000BASE-SX (MT-RJ Type) SFP GBIC.
Wavelength 1300 nm
Optical budget 10.5 dB
Laser Transmitter Characteristics
Minimum launch power -9.0 dBm
Maximum launch power -3 dBm
Receiver Characteristics
Minimum receiver
sensitivity -20 dBm
Maximum input power -3 dBm
Table 12 1000BASE-SX (MT-RJ Type) SFP GBIC
specifications
Type Specifications
Standards Conformity to the following standards:
802.3z, Ethernet full duplex
Connectors Duplex MT-RJ fiber optic connector
Table 11 1000BASE-LX SFP GBIC specifications
Type Specifications
