: Heater Lamp Cover

Left Heater Lamp Cover

I

Heater Lamp Cover

-do221

: Heater Lamp

3. Remove the Left

Lamp Cover. (1 screw)

Note: When removing the Left Heater Lamp

Cover, turn the Cover in the clockwise

direction.

4. Remove the Right Heater

Cover.

Note: When removing the Right Heater Lamp

Cover, turn the Cover in the counter

direction.

the stopper and

the Heater Lamp in the direction indicate

by the arrow, remove it from the heater

D-3
