Reference Manual for the Model DG814 DSL Modem Internet Gateway
6-6 Maintenance
Click the “Ping Status” button to perform a connectivity test from your gateway, as shown in
Figure 6-4 below.
Figure 6-4. Ping Status screen
This screen allows you to “ping” an IP address on the LAN to verify connectivity. Enter the IP
address and click the “PING” button to perform the test.
Attached Devices
The Attached Devices menu contains a table of all IP devices that the gateway has discovered on
the local network. From the Main Menu of the browser interface, under the Maintenance heading,
select Attached Devices to view the table, shown in
Figure 6-5
Figure 6-5. Attached Devices menu
