Reference Manual for the ProSafe Wireless 802.11g VPN Firewall Model FVG318
Introduction 2-7
v1.0, October 2005
Table 2-1. LED Descriptions
LED Label Activity Description
PWR On Power is supplied to the firewall.
TEST On
Off The system is initializing.
The system is ready and running.
INTERNET
100 (100 Mbps) On
Off The Internet (WAN) port is operating at 100 Mbps.
The Internet (WAN) port is operating at 10 Mbps.
LINK/ACT
(Link/Activity)
On
Blinking The Internet port has detected a link with an attached device.
Data is being transmitted or received by the Internet port.
LOCAL
100 (100 Mbps) On
Off The Local port is operating at 100 Mbps.
The Local port is operating at 10 Mbps.
LINK/ACT
(Link/Activity)
On
Blinking The Local port has detected a link with an attached device.
Data is being transmitted or received by the Local port.
WLAN On/Blink
Off The wireless interface is on/data transmission in progress.
The wireless interface is off.
