16
3. Installation instructions
for the qualified installer
3.1 Unit structure
D H L M N
15 Control panel
16 Hot water outlet nozzle G ½
17 Cold water inlet nozzle G ½
18 Heating element
19 Parasitic current anode
20 Electronic module (control unit)
21 Reset button of safety thermal cut-out
22 Electronic module (regulation)
23 Safety thermal cut-out
24 Sealing ring
25 Draining valve with hose connection G ¾
26 Aperture for customer provided remote
control of rapid heating in combination
with PG 11
27 Cable aperture PG 21 for electrical
connection
28 Inflow
29 Outflow pipe
30 Suspension bracket, top*
31 Suspension bracket, bottom*
(SHZ 120 LCD, SHZ 150 LCD only)
32 Connection cable for „electronic
modules“
33 Sliding switch for operating modes
34 Sliding switch for output variants
35 Unit connection terminal
36 Temperature sensor
37 Parasitic current anode
38 Customer provided remote control for
rapid heating
39 Customer provided power supply
company contact
* for customer provided screws 12 mm dia.
3.2 Fittings
! Unvented (pressurized) mode of
operation: Safety groups kV 30 or kV 40
F .
! Vented (pressureless) mode of operation:
Fittings without pressure G .
3.3 Regulations and
provisions
! The installation (water and electrical
installation) and first start-up, as well as the
maintenance of this unit may only be
carried out by an approved specialist
installer in accordance with these
Instructions.
! Perfect function and operational safety are
only guaranteed with original accessories
and spare parts intended for the unit.
! IEE Regulations (electrical).
! Provisions of the local energy supply utility
company.
! WRC Regulations (water).
! Provisions of the water supply utility
company responsible.
The following are also to be respected:
! The unit rating plate
! Technical data
! Water installation
Pipe material:
– Cold water pipe – Hot water pipe
Copper pipe Copper pipe
Steel pipe Steel or copper pipe
Plastic pipe systems:
Installation also in conjunction with
DVGW-tested plastic pipe system for
cold-water and hot-water pipe systems.
! Electrical installation
– Electrical connection only with fixed-laid
leads in association with removable
cable bushings.
– The unit must be capable of all-pole
disconnection from the mains, for
example by fuses, with an isolating
distance of at least 3 mm.
3.5 Installation location
! Install in a vertical position; see D .
! In an area not subject to the risk of
freezing.
! Install close to the water tap.
3.6 Unit installation
E
! Fit the suspension bracket.
Select the securing material to suit the
strength of the wall. With SHZ 120 LCD
and SHZ 150 LCD, two suspension
brackets are required.
Any unevenness in the wall is to be
compensated for by the spacer elements
C provided (a. approx. 5 mm thick).
! Suspend the unit.
! Push the cover caps onto the suspension
bracket (b).
3.7 Water connection
! Unvented (pressurized) for the
supply of several draw-off points.
– Install the type-tested safety groups F
KV 30, Order No. 00 08 26, up to
0.48 MPa water pipe pressure
KV 40, Order No. 00 08 28, up to 1 MPa
water pipe pressure
a Safety valve
b Backflow preventer
c Test valve
d Throughflow isolating valve (choke)
e Pressure reducer (with KV 40)
f Test nozzle for pressure gauge
g Thermostat fitting TA 260
Order No. 00 34 66 (order
separately), also possible in conjunction
with KV 40.
– Establish dimensions for the outflow pipe
for a fully-opened safety valve. The drain
aperture of the safety valve must remain
open to the atmosphere.
– The drain for the safety group is to be
installed with a constant downwards
inclination.
– The information provided in the
Installation Instructions for the safety
group are to be respected.
– Set a maximum flow rate of 18 l/min at
the choke of the safety group.
! Vented (pressureless) for the supply
of one single draw-off point
The units are suitable for vented
(pressureless) operation mode.
Do not block off the drain and
fittings pivot arm.
– With this installation the Stiebel Eltron
fittings for vented wall-mounted water
heaters
G are to be used.
– Before connecting the fitting the water
pipe must be thoroughly flushed through.
– Each time heating takes place, expansion
water will drip out of the drain.
– For use, installation, first start-up, and
maintenance, the same instructions apply
as for the operation of unvented
(pressurized) water heaters.
Technical data
(the data on the unit rating plate are applicable)
Type SHZ 30 SHZ 50 SHZ 80 SHZ 100 SHZ 120 SHZ 150
LCD LCD LCD LCD LCD LCD
Mixed water quantity l 59 97 159 198 235 292
40 °C (15 °C / 65 °C)
Capacity l 30 50 80 100 120 150
Weight empty kg 23.5 30 44 45 50 62.5
Connectable to power 1 - 4 kW 1/N/PE ~ 230 V
sources 1 - 4 kW 2/N/PE ~ 400 V
1 - 6 kW 3/N/PE ~ 400 V
Permissible operating
pressure 0.6 MPa (6 bar)
Table 1
Protection class
EN 60529 IP 25 D
Test marking See unit rating plate
Water connection G ½ (external thread)
Flow rate max. 18 l/min
Dimensions a mm 420 510 510 510 510 510
D b mm 410 510 510 510 510 510
h mm 750 720 1030 1030 1190 1425
i mm – – – – 300 300
k mm 700 600 900 900 900 1100
l mm 70 140 150 150 310 345
