background image

© National Instruments Corporation

A-1

NI PCI-5911 User Manual

A

Specifications

This appendix lists the specifications of the NI 5911. These specifications
are typical at 25

°C unless otherwise stated.

Acquisition System

Bandwidth .............................................. 100 MHz maximum;

refer to Table 2-2,

Available

Sampling Rates and
Corresponding Bandwidth in
Flexible Resolution Mode

Number of channels ............................... 1

Number of flexible resolution ADC....... 1

Max RIS sample rate.............................. 1 GS/s

Max real-time sample rate...................... 100 MS/s

Resolution

Sample Rate

Mode

Effective Resolution

100/n

*

MS/s

Conventional

8 bits

12.5 MS/s

Flexible Resolution

11 bits

5 MS/s

Flexible Resolution

14 bits

2.5 MS/s

Flexible Resolution

15.5 bits

1 MS/s

Flexible Resolution

17.5 bits

500 kS/s

Flexible Resolution

18 bits

200 kS/s

Flexible Resolution

18.5 bits

100 kS/s

Flexible Resolution

19 bits

50 kS/s

Flexible Resolution

19.5 bits
