November 2005 Installing the server and connecting the peripheral devices
Part 2: 703t Server Hardware Installation 59
Connecting the server to the CLAN
(optional)
Introduction
This section provides instructions to connect the server to the Customer
LAN (CLAN).
Note: The CLAN connection is optional. However, connection to a CLAN
is required for support of desktop and web messaging users, or
administration by means of a web-enabled PC.
To connect the server to the CLAN
1 Locate the CLAN connector on the back of the server.
Note: The CLAN connector is labeled as NIC2 1GB. For the connector
location, see the diagram on page 54.
2 Connect an RJ-45 network cable from the CLAN hub to the CLAN
connector.
What’s next?
Continue with “Installing the Nortel Networks software feature key adapter”
on page 60.
ATTENTION
If a hub is required or used, it must be located at least 6 m
(20 ft) away from the 703t server. This ensures compliance
with EMC requirements.
