Preinstallation requirements
Part 2: 703t Server Hardware Installation
33
4
Replace the server cover.
❒
5
Place the 703t server in the chosen location (see page 48).
❒
6
Set the DIP switches on the modem (see page 51).
❒
7
Connect the 703t server and devices as follows:
Connect the monitor, keyboard, and mouse (see page 53).
❒
Connect the modem (see page 55).
❒
Connect the 703t server to the ELAN hub (see page 57).
ATTENTION
If a hub is required or used, it must be located at least 6 m
(20 ft) away from the 703t server. This ensures compliance
with EMC requirements.
❒
Connect the 703t server to the CLAN hub (optional); (see
page 59).
ATTENTION
If a hub is required or used, it must be located at least 6 m
(20 ft) away from the 703t server. This ensures compliance
with EMC requirements.
❒
Install the software feature key adapter (see page 60).
❒
Connect the power cords for all devices, and then power
them up (see page 62).
❒
8
Start the 703t server (see page 64).
❒
Step
Description
Check
