November 2005 703t server description
Part 2: 703t Server Hardware Installation 15
IDE CD-ROM drive
(5.25 in.) Enables you to use the CallPilot software and
documentation CD-ROMs.
CD drive eject
button Opens the CD-ROM drawer. Push the button
again to close the drawer.
Backup tape drive Allows backup of hard drive data.
Hard drive 1 10,000 rpm hard drive
Hard drive 2 10,000 rpm hard drive
Drive bay Vacant
Drive bay Vacant
Drive bay Vacant
Air flow slot Must remain empty for proper system cooling.
Part Function
