34
S S S S Sp p p p pe ee eecccccif if if if ific ic ic ic icat at at at ations ions ions ions ions
LCD Module Diagonal : 23.0 inch Active matrix; thin film transistor (TFT)
Viewable Image Size : 23.0 inch liquid crystal display (LCD); 0.390 mm dot
Native Resolution (Pixel Count) : 1280 x 768 pitch; 500cd/m 2 white luminance;
500:1 contrast ratio, typical
Input Signal PC INPUT
Video : ANALOG 0.7 Vp-p/75 Ohms Digital Input: DVI
Sync : Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
VIDEO INPUT Composite 1.0V p-p Input Impedance 75 Ohm RCA-INPUT
Y/C Y:0.7V p-p C:0.283V p-p Input Impedance 75 Ohm S-TERMINAL-INPUT
2 component 1.0/0.7V p-p Input Impedance 75 Ohm RCA-INPUT
AUDIO INPUT RCA PIN-JACK L/R 3 INPUT, STEREO Mini Jack 1INPUT
500mV rms Input Impedance 22 Kohm
AUDIO OUTPUT RCA PIN-JACK L/R 1OUTPUT 500mV rms
RCA PIN-JACK Subwoofer 1 OUTPUT 300mV rms
Display Colors Over 16,000,000 Dependent on display card used.
Maximum Left/Right : 85°/85° (CR>10)
Viewing Angles Up/Down : 85°/85° (CR>10)
Synchronization Horizontal : 31.5 kHz to 60.0 kHz Automatically
Range Vertical : 56.0 Hz to 75.0 Hz Automatically
Resolutions Supported 720 x 400* 1 :VGA text Some systems may not support all modes listed.
640 x 480* 1 @ 60 Hz to 75 Hz
800 x 600* 1 @ 56 Hz to 75 Hz
1024 x 768* 1 @ 60 Hz to 75 Hz
1280 x 768 @ 60 Hz to 75 Hz...................NEC-Mitsubishi Electronics Display cites
1152 x 864*
1 @ 60 Hz to 70 Hz recommended resolution at 60 Hz for
1280 x 960* 1 @ 60 Hz to 70 Hz optimal display performance.
1280 x 1024* 1 @ 60 Hz to 70 Hz
NTSC
HDTV: 480i (60 Hz), 480p (60 Hz), 576i (50 Hz), 720p (50/60 Hz), 1080i (50/60
Hz)
Active Display Area
Horizontal : 19.7 inch
Vertical : 11.8 inch
Power Supply 100 – 240 V ~ 50/60 Hz
Current Rating 19V DC 6.3A
Dimensions 580.0 mm (W) x 467.5 mm (H) x 210.0 mm (D)
22.8 inches (W) x 18.4 inches (H) x8.3 inches (D)
Weight 10.0 kg
22.0 lbs
Environmental Considerations
Operating Temperature : 5°C to 35°C/41°F to 95°F
Humidity : 30% to 80%
Feet : 0 to 12,001 Feet
Storage Temperature : -10°C to 60°C/14°F to 140°F
Humidity : 10% to 85%
Feet : 0 to 40,000 Feet
* 1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear
different. This is normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat
panel technologies, each dot on the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the
resolution must be done.
NOTE: Technical specifications are subject to change without notice.
