Appendix A

Specifications

©

National Instruments Corporation

A-9

PCI-6023E/6024E/6025E User Manual

Pulse width ............................................. 10 ns min

RTSI

Trigger lines ........................................... 7

Calibration

Interval ................................................... 1 year

Onboard calibration reference

Level ............................................... 5.000 V (±3.5 mV) (actual

value stored in EEPROM)

Temperature coefficient .................. ±5 ppm/°C max

Long-term stability ......................... ±15 ppm/

Power Requirement

+5 VDC (±5%)....................................... 0.7 A

Power available at I/O connector ........... +4.65 VDC to +5.25 VDC at 1 A

Physical

Dimensions (not including
connectors) ............................................. 17.5 by 10.6 cm (6.9 by 4.2 in.)

I/O connector

PCI-6023E/6024E ........................... 68-pin male SCSI-II type

PCI-6025E ...................................... 100-pin female 0.05D type

Operating Environment

Ambient temperature.............................. 0° to 55° C

Relative humidity ................................... 10% to 90% noncondensing

Storage Environment

Ambient temperature.............................. -20° to 70° C

Relative humidity ................................... 5% to 95% noncondensing

1 000 h

,

PCI.book Page 9 Wednesday, September 16, 1998 9:09 AM
