Index
© National Instruments Corporation I-9 PCI-6023E/6024E/6025E User Manual
V
VCC signal (table), 4-7
VirtualBench software, 1-3
voltage output specifications, A-6
W
waveform generation, questions about,
C-2 to C-3
waveform generation timing connections,
4-40 to 4-43
UISOURCE signal, 4-42 to 4-43
UPDATE* signal, 4-41 to 4-42
WFTRIG signal, 4-40 to 4-41
WFTRIG signal, 4-40 to 4-41
WR* signal
description (table), 4-26
mode 1 output timing (figure), 4-28
mode 2 bidirectional timing (figure), 4-29
