Appendix A
Specifications
PCI-6023E/6024E/6025E User Manual
A-6
©
National Instruments Corporation
Voltage Output
Range ......................................................± 10 V
Output coupling ......................................DC
Output impedance...................................0.1
Ω
max
Current drive...........................................±5 mA max
Protection................................................Short-circuit to ground
Power-on state ........................................0 V
Dynamic Characteristics
Settling time for full-scale step...............10 µs to ±0.5 LSB accuracy
Slew rate .................................................10 V/µs
Noise .......................................................200 µVrms, DC to 1 MHz
Glitch energy (at midscal transition)
Magnitude ..............................................
± 12 mV
Duration........................................... 2.0 µs
Stability
Offset temperature coefficient ................± 50 µV/°C
Gain temperature coefficient ..................±25 ppm /°C
Digital I/O
Number of channels
PCI-6025E .......................................32 input/output
PCI-6023E and PCI-6024E .............8 input/output
Compatibility ..........................................TTL/CMOS
