Chapter 4

Blob Analysis

IMAQ Vision for LabWindows/CVI User Manual

4-6

ni.com

IMAQ_MAX_SEGMENT_LEFT_COLUMN

leftmost x-coordinate of longest horizontal line segment
in a particle

IMAQ_MAX_SEGMENT_TOP_ROW

y-coordinate of longest horizontal line segment

IMAQ_PERIMETER

length of the outer contour of the particle in user-defined
units

IMAQ_PERIMETER_OF_HOLES

perimeter of all holes in user-defined units

IMAQ_SIGMA_X

sum of the x-coordinates for each pixel of the particle

IMAQ_SIGMA_Y

sum of the y-coordinates for each pixel of the particle

IMAQ_SIGMA_XX

sum of the squared x-coordinates for each pixel of the
particle

IMAQ_SIGMA_YY

sum of the squared y-coordinates for each pixel of the
particle

IMAQ_SIGMA_XY

sum of the product of the x-coordinate and y-coordinate
for each pixel of the particle

IMAQ_PROJ_X

sum of the vertical segments in a particle

IMAQ_PROJ_Y

sum of the horizontal segments in a particle

IMAQ_INERTIA_XX

inertia matrix coefficient in XX

IMAQ_INERTIA_YY

inertia matrix coefficient in YY

IMAQ_INERTIA_XY

inertia matrix coefficient in XY

IMAQ_MEAN_H

mean length of horizontal segments

IMAQ_MEAN_V

mean length of vertical segments

IMAQ_MAX_INTERCEPT

length of the longest segment of the convex hull of the
particle

IMAQ_MEAN_INTERCEPT

mean length of the chords in a particle perpendicular to
its max intercept

IMAQ_ORIENTATION

direction of the major axis of a particle

IMAQ_EQUIV_ELLIPSE_MINOR

total length of the minor axis of the ellipse having the
same area as the particle and a major axis equal to half
the max intercept

Table 4-1. Particle Measurements (Continued)

Measurement

Description
