- 130 -
Creating Zone
Port mode zoning
For port mode zoning, use the domain ID and port number of the FC Switch Module to set zoning.
1) Checking domain ID
1. Type "switchshow" on the console screen.
„ Any commands used on the switch console should be specified with
lowercase letters.
2. The information on the status of FC Switch Modules appears.
See values of "switchDomain" for the domain ID (the value is set to 1 at shipment).
WH040000350:admin> switchshow
switchName: WH040000350
switchType: 43.1
switchState:
Online
switchMode: Native
switchRole: Principal
switchDomain: 1
switchId: fffc01
switchWwn: 10:00:00:05:1e:02:08:53
zoning: OFF
switchBeacon: OFF
Area Port Media Speed State
==============================
0 0 -- 4G No_Module (No POD License) Disabled
1 1 cu 4G No_Sync
2 2 cu 4G No_Sync Disabled (Persistent)
3 3 cu 4G No_Sync Disabled (Persistent)
4 4 cu 4G Online F-Port 10:00:00:00:c9:51:fe:c0
5 5 cu 4G No_Sync Disabled (Persistent)
6 6 cu 4G No_Sync Disabled (Persistent)
7 7 cu 4G No_Sync Disabled (Persistent)
8 8 cu 4G No_Sync Disabled (Persistent)
9 9 cu 4G No_Sync (No POD License) Disabled (Persistent)
10 10 cu 4G No_Sync (No POD License) Disabled (Persistent)
11 11 cu 4G No_Sync (No POD License) Disabled (Persistent)
12 12 cu 4G No_Sync (No POD License) Disabled (Persistent)
13 13 cu 4G No_Sync (No POD License) Disabled (Persistent)
14 14 cu 4G No_Sync (No POD License) Disabled (Persistent)
15 15 cu 4G No_Sync (No POD License) Disabled (Persistent)
16 16 cu 4G No_Sync (No POD License) Disabled (Persistent)
17 17 id 4G Online F-Port 20:01:00:30:13:84:09:42
18 18 id 4G Online F-Port 20:02:00:30:13:84:09:42
19 19 id 4G Online F-Port 20:05:00:30:13:84:09:42
20 20 id 4G Online F-Port 20:06:00:30:13:84:09:42
21 21 -- 4G No_Module (No POD License) Disabled
22 22 -- 4G No_Module (No POD License) Disabled
23 23 -- 4G No_Module (No POD License) Disabled
WH040000350:admin>
„ If the domain ID is changed after port mode zoning, the zoning for the new
domain ID must be set.
„ Check the value of "switchname" in "switchshow" to check that the FC
Switch Module is subject to zoning.
