Appendix A Specifications
© National Instruments Corporation A-7 PCI-4451/4452 User Manual
Dynamic Characteristics
Image-free bandwidth ............................ DC to 0.450 f
s
Image rejection....................................... 90 dB, 0.550 f
s
< f
out
< 63.450 f
s
Spurious-free dynamic range ................. 90 dB, DC to 100 kHz
THD
....................................................... −
80 dB;
−
90 dB for f
out
< 5 kHz
or signal < 1 V
rms
IMD
........................................................ −
90 dB (CCIF 14 kHz + 15 kHz)
Crosstalk (channel separation)
............... −
80 dB, DC to 23 kHz
Phase linearity ........................................ ±1°
Interchannel phase.................................. ±1°
(same configuration
both output channels)
Interchannel gain mismatch ................... ±0.1 dB, for all attenuations
(same configuration
both output channels)
Signal delay............................................ 34.6 ±0.5 sample periods, any
sample rate (time from when
digital data is expressed to when
analog signal appears at output
terminals)
Digital I/O
Number of channels ............................... 8 input/output
Compatibility ......................................... TTL/CMOS
