Chapter 1
Introduction
©
National Instruments Corporation
1-5
PCI-4451/4452 User Manual
•
To create your own accessories, you can use an AMP 68-pin
right-angle PWB receptacle header, part number 787254-1.
•
Recommended manufacturer part numbers for the 68-pin mating
connector for the cable assembly are as follows:
–
AMP 68-position straight cable plug, part number 787131-3
–
AMP 68-position backshell with jackscrews, part number
787191-1
National Instruments also offers cables of different lengths and accessories
to connect your digital I/O signals to the PCI-4451/4452. To develop your
own cable, the mating connector for the digital I/O is a 50-position
receptacle. For a connector pinout assignment, refer to Table 4-3,
. Recommended manufacturer part numbers
for this mating connector are as follows:
•
50-position straight cable plug, part number 787131-1
•
50-position backshell with jackscrews, part number 787233-1
Refer to Appendix B,
, for pin assignments of digital
accessories and cables.
