NETGEAR DSL Modem Internet Gateway DG814 - Manual (Page 56)

Reference Manual for the Model DG814 DSL Modem Internet Gateway
5-2 Maintenance
Figure 5-1. Gateway Status screen
This screen shows the following parameters:
Table 5-1. Gateway Status Fields
Field Description
System Name This field displays the Host Name assigned to the gateway.
Firmware Version This field displays the gateway firmware version.
WAN Port These IP parameters apply to the ADSL (WAN) port of the gateway.
IP Address This field displays the IP address being used by the ADSL (WAN) port of
the gateway. If no address is shown, the gateway cannot connect to the
Internet.
IP Subnet Mask This field displays the IP Subnet Mask being used by the ADSL(WAN)
port of the gateway.
