English-18
Main Menu Sub Menu Sub Menu2 Sub Menu3 Explanation Default Reset
OPTION3
(continued)
VIDEO WALL Sets the confi guration of video wall.
DIVIDER Sets the video wall. OFF YES
POSITION Sets the position of each display.
DISP. MODE Sets the mode of seam processing for each display. SPLIT YES
SCREEN ASPECT
MODE Adjusts detail position.
V-POSITION 0 YES
H-POSITION 0 YES
V-HEIGHT 0 YES
H-WIDTH 0 YES
AUTO
PICTURE OFF YES
CLOCK
PHASE 0 YES
CLOCK 0 YES
UNDER
SCAN OFF YES
P.ON DELAY Adjusts the delay time between being in “standby” mode
and entering “power on” mode. OFF YES
OPTION4
Available only
when the
Advanced OSD
function is
enabled. SUB PICTURE Automatically detects if there is an input signal for the sub
screen. This feature is available only picture-in-picture
mode.
SUB P.
DETECT Automatically detects sub screen. AUTO YES
DISPLAY Sets the appearance of the sub screen. NORMAL YES
SUB P. RATE Sets the transparency of the sub screen. 100% YES
ZOOM NAV Sets the position of the zoom navigation image. BTM LFT YES
PIC FREEZE Sets the position of the captured still picture. S BY S1 YES
QUICK SWAP Enables quick swapping of input.
Sets which input terminals are used. OFF YES
SELECT1 VIDEO1 YES
SELECT2 VGA YES
TEXT INSERT Allows text insertion within main screen. OFF YES
INPUT Sets the input of text image of the VGA, RGBHV, and DVI. VGA YES
SUB P.
DETECT Automatically detects sub screen. AUTO YES
DISPLAY Sets the appearance of the sub screen. NORMAL YES
SUB P. RATE Sets the transparency of the sub screen. 100% YES
ADVANCED
OSM ON: All menu items are shown for advanced users.
OFF: Some of the advanced menu items are not shown. OFF YES
LANGUAGE Select the language used by the OSD. ENGLISH NO
COLOR
SYSTEM The Color System that is used depends on the video
format of the input signal.
VIDEO input only. AUTO NO
SOURCE
INFORMATION Display information about the display: frequencies,
polarities, etc.
On-Screen Display (OSD)
