NEC 42XP10 - Manual (Page 20)

English-17
On-Screen Display (OSD)
Main Menu Sub Menu Sub Menu2 Sub Menu3 Explanation Default Reset
OPTION2
Available only
when the
Advanced OSD
function is
enabled. POWER SAVE Sets how long the monitor waits before going into power
save mode after a signal is lost.
VGA, RGBHV, and DVI input and Separate HV Sync. only. OFF YES
FILM MODE Selects Film mode. ON YES
SCREEN SAVER Use SCREEN SAVER functions to reduce the risk of image
retention.
PLE PLE: The brightness is decreased in order of Lock mode.
(the higher number is darker) AUTO YES
ORBITER ORBITER: The screen image moves and is slightly
squeezed or expanded. AUTO1 YES
INVERSE WORKING TIME
/WAITING TIME INVERSE: The screen image is displayed alternately
between positive image and negative image, or the screen
image is displayed full white. OFF YES
COOLING FAN Cooling fan reduces the temperature of the display. AUTO NO
SIDE MASK Adjusts the color of the side mask when a 4:3 image is
displayed.
Press + button, the bar will become lighter.
Press - button, the bar will become darker. 3 YES
PICTURE SIZE When it is set to "OFF", TRUE of picture size appears only
RGB signals. ON YES
DVI MODE PLUG/PLAY Choose the DVI mode based on the input device
connected via DVI connector and set the black level.
When a PC or similar equipment is connected, the PLUG/
PLAY setting should be "DVI-PC" and the BLACK LEVEL
setting should be "LOW".
When a DVD player or similar equipment is connected,
PLUG/PLAY setting should be "DVI-HD" and the BLACK
LEVEL setting should be "HIGH". DVI-PC NO
BLACK LEVEL LOW NO
PROTOCOL SET Sets protocol setting for use with RS-232C connection.
OFF: When NEC protocol is used (normal).
ON: When special protocol is used.
Consult dealer for details of protocol. OFF YES
CLOSED CAPTION
U.S. models only Choose the closed caption setting. OFF YES
CAPTION CONT
U.S. models only Chooses the brightness of the closed captions. NORMAL YES
OPTION3
Available only
when the
Advanced OSD
function is
enabled. TIMER PRESENT
TIME DAYLIGHT
SAVING
TIME Sets the date, time, and daylight saving region.
Day & time must be set in order for the “TIMER” function
to operate. OFF NO
DAY/HOUR/
MINUTE NO
TIMER Creates a working schedule for the monitor to use. See
page 24 for instructions. OFF YES
INPUT DETECT INPUT Sets the input mode and the sound volume when the
power is turned on.
LAST: Uses the input that was last selected when the
power was turned off.
MULTI to DVI: Fixed input mode.
AUTO: Automatically searches for the input signal.
PRIORITY: Sets which input has priority when using the
AUTO setting. LAST YES
VOLUME LAST YES
CONTROL LOCK This function completely locks out access to all Control
Key functions. When this item is set to "ON", the front
panel is disabled as soon as the on-screen menu goes off. OFF YES
IR REMOTE When "OFF", prevents the monitor from being controlled
by wireless remote controller. The remote becomes
ineffective disabled as soon as the on-screen menu goes
off. To return to normal operation, press the “DISPLAY”
button on the remote controller for 5 seconds. ON YES
LOOP OUT Change the loop out setting. OFF YES
MONITOR ID Sets the Monitor ID to a number from 1-26 and or to ALL. ALL YES
RS232C CONTROL Selects the mode of the monitor when using the RS-232C
daisy chain. NORMAL YES
