English

English-16

On-Screen Display (OSD)

Main Menu

Sub Menu

Sub Menu2

Sub Menu3

Explanation

Default

Reset

SCREEN

ASPECT MODE

Selects aspect ratio of the displayed image. Press + or
- to select.

V-POSITION

Controls the vertical position of the image within the
Display area of the PDP.
Press + to move up. Press - to move down.

0

YES

H-POSITION

Controls the horizontal position of the image within the
Display area of the PDP.
Press + to move right. Press - to move left.

0

YES

V-HEIGHT

Adjusts the vertical size of the image.

0

YES

H-WIDTH

Adjusts the horizontal size of the image.

0

YES

AUTO PICTURE

ON: H-Position, V-Position, Clock and Clock Phase are
adjusted automatically.
OFF: H-Position, V-Position, Clock and Clock Phase are
adjusted manually.
VGA and RGBHV input only.

OFF

NO

CLOCK PHASE

Adjusts the visual “noise” on the image.
VGA and RGBHV input only.

0

YES

CLOCK

Press + to expand the width of the image on the right of
the screen.
Press - to narrow the width of the image on the left.
VGA and RGBHV input only.

0

YES

UNDER SCAN
Available only when
the Advanced OSD
function is enabled.

ON: UNDERSCAN is selectable in the ASPECT MODE
menu.
OFF: UNDERSCAN item is not selectable in the ASPECT
MODE menu.
Video signal input only.

OFF

YES

OPTION1

OSD

DISPLAY OSD

ON: Information about inputs, screen size, etc. is shown.
OFF: No information is shown.

ON

YES

OSD
POSITION

Change the position of the menu between 1 and 6. Press
+ or - to adjust.

1

YES

OSD ORBITER

ON: The menu position intermittently shifts eight dots
while the OSD is being displayed.
OFF: The menu position does not shift.

OFF

YES

OSD TRANSP.

Adjusts the transparency level of the OSD.
Press + or - to adjust.

70%

YES

BNC INPUT

Selects the input type when using 5BNC connectors.
RGB: For RGB input.
COMP.: For Component input (3BNC connectors).
SCART1: For SCART input (4BNC connectors).
SCART2: For SCART input (3BNC connectors and VIDEO1
input).
SCART1, SCART2 available for Europe and World-Wide
models only.

RGB

YES

D-SUB INPUT

Selects the input type when using a mini D-SUB
connector.
RGB: For RGB input.
SCART3: for SCART input.
SCART3 available for Europe and World-Wide models
only.

RGB

YES

RGB SELECT

If there is a problem with signal detection, this function
forces the monitor to display the signal at the desired
resolution.
If no problem is detected, the only available option will be
“AUTO”.
VGA and RGBHV input only.

AUTO

YES

HD SELECT

Manually selects signal output when similar 1080I signal
are detected.
1080B: Standard digital broadcasts.
1080A: Special digital broadcasts (ex. DTC100).

1080B

NO

INPUT SKIP

Skips to next input if present input signal is not detected.
This function is valid only for INPUT key on the display.

OFF

YES

ALL RESET

Resets settings back to factory default values.

OFF
