5. Using On-Screen Display
68
Image Options Menu
The Image Options menu is used to configure image options such as screen positioning
and aspect ratio. Access the image options menu in the Adjust menu.
The following table lists all functions with a description and the default setting.
I
TEM
D
ESCRIPTION
Aspect
Ratio
Select Aspect Ratio using ◄or► from the list (see page 69 ).
Overscan Set the Overscan value using ◄or► (see page 72 ).
Position/
Clock
Adjust the Position/Clock values using the slides.
Horizontal: Adjusts the image location horizontally using ◄or►.
Vertical:
Adjusts the image location vertically using ◄or►.
Clock: Fine tune a computer image or remove any vertical banding
that might appear.
Phase: Adjust the clock phase or reduce video noise, dot interference
or cross talk.
Note:
Only use the Phase settings after the clock settings have been
modified.
WXGA Mode
(NP4001 only)
Select WXGA mode (see page 72 ).
