NETGEAR Double 108 Mbps Wireless USB 2.0 Adapter WG111U User Manual
Windows xp
Table of contents
Document Outline
- Windows XP
- 1. First, install the WG111U software.
- a. Power on your computer, let the operating system boot up completely, and log in as needed. Insert the Resource CD for the WG111U into your CD drive. The CD main page will load.
- b. Click the Install Driver and Utility link. Follow the InstallShield Wizard steps.
- c. Click Finish when done, and if prompted restart your computer.
- 2. Next, install the WG111U Wireless USB 2.0 Adapter.
- a. Locate an available USB port on your PC. Connect the USB cable to the WG111U and insert the other end of the cable into the USB slot on your PC.
- b. After a short delay, the Found New Hardware Wizard displays. Select Install the software automatically (Recommended) and click Next.
- c. Next you will be prompted to enable the NETGEAR Smart Wireless Settings Utility configuration utility.
- d. You will also be prompted to choose the country you are located in. Select your location from the list.
- e. Click Finish to complete the installation. You will see the WG111U system tray icon on the lower right portion of the Windows task bar.
- 3. Now, configure your WG111U and save the Profile.
- a. Determine the current settings for your wireless access point, including the case- sensitive SSID and security settings (if any):
- b. Click the WG111U icon in the Windows system tray to open the WG111U Smart Wireless Settings Utility. The utility opens to the Settings tab page, as shown below.
- c. Change the Network Name SSID and security settings to match your wireless access point. The default SSID is NETGEAR_11g. WPA-PSK security is enabled by default and the Passphrase is NETGEAR-ULTRA-G.
- d. Click Apply to activate the connection.
- 4. Finally, verify wireless network connectivity.
- a. Verify that the status monitor information at the bottom of the utility matches your wireless network.
- b. Check the color of the WG111U icon in the Windows system tray: green or yellow indicates a working connection; red indicates no connection.
- c. Check the WG111U LED: blinking means attempting to connect; solid indicates a good connection; off means the WG111U is not plugged in.
- d. Verify connectivity to the Internet or network resources.
- 1. First, install the WG111U software.
- Windows 2000, ME, 98SE
- 1. First, install the WG111U software.
- a. Power on your computer, let the operating system boot up completely, and log in as needed.
- b. Insert the Resource CD for the WG111U into your CD drive. The CD main page shown below will load.
- c. Click the Install Driver and Utility link.
- d. Follow the InstallShield Wizard steps.
- e. Click Finish when done, and if prompted restart your computer.
- 2. Next, install the WG111U Wireless USB 2.0 Adapter.
- a. Locate an available USB port on your PC. Connect the USB cable to the WG111U and insert the other end of the cable into the USB slot on your PC.
- b. After a short delay, the Found New Hardware Wizard displays. Select Install the software automatically (Recommended) and click Next.
- c. Follow the Found New Hardware Wizard steps, click Finish when done, and if prompted, restart your computer.
- d. Next, you will be prompted to choose the country where you are located. Select your location from the list.
- e. You will now see the WG111U system tray icon in the lower right area of the Windows task bar.
- 3. Now, configure your WG111U and save the Profile.
- a. Determine the current settings for your wireless access point, including the case- sensitive SSID and security settings (if any):
- b. Click the WG111U system tray icon to view to the Settings tab page:
- c. Change the Network Name SSID and security settings to match your wireless access point. The default SSID is NETGEAR_11g. WPA-PSK security is enabled by default and the Passphrase is NETGEAR-ULTRA-G.
- d. Click Apply to activate the connection.
- 4. Finally, verify wireless network connectivity.
- a. Verify that the status monitor information at the bottom of the utility screen matches your wireless network.
- b. Check the color of the WG111U icon in the Windows system tray: green or yellow indicates a working connection; red indicates no connection.
- c. Check the WG111U LED: blinking means attempting to connect; solid indicates a good connection; off means the WG111U is not plugged in.
- d. Verify connectivity to the Internet or network resources.
- Determining Placement of the USB Adapter
- Technical Support
