PARTS AND FUNCTIONS
Names of battery parts and their functions
Battery knob
DC IN connector
Battery indicator LED
Player terminals
Fix pole
DC OUT (Non-standard jack)
Connect the power adapter to recharge(AC/DC adapter).
Su pply pow er to the player.
Do no t short-c ircuit the termina ls.
CAU TION:
When the battery is discharging, LED is off.
When recharging the battery, LED is red.
When the LED turns from RED to off, means fi nishing recharge.
1
2
3
4
5
6
Fix the battery to the player when installing battery.
Output DC 7.4/7.2V. Especially for supplying power to TV Tuner
Box (Optional accessory).
Tw ist it to t ighten/d etach the battery pack.
