Ma in unit right panel
Loader s tatus indicator LED
Indicat e loader status.
PARTS AND FUNCTIONS
Ear phone jack
Volume control
Video in/out j ack
Audio in/out and optical output ja ck
DC in
For co nnecting a stere o earpho ne or an amplifie r.
Use it to adjust th e volum e of the s peakers or earphone.
Inpu t or outp ut video signals to conne cted dev ice by se tting AV IN/OUT mode va lue.
The included AV cabl e is conn ected here.
Conne ct the included A C adapt er here.
Input or output audio signals to co nnected device by setting AV IN/ OUT mode value.
Output o ptical audio sign als to connected device.
The incl uded AV cable or optical d igital cable is connected here.
