RJ-11 Connector
Pin Assignment
Normal Assignment
1 Not
Connected
2 Not
connected
3 Line
4 Line
5 Not
Connected
6 Not
Connected
RJ11 connector and cable
An RJ-11 connector is the small, modular plug used for most analog telephones. It
has six pin slots in the head, but usually only two or four of them are used.
Figure 5
605 to RJ-11 adapter
The 605 to RJ-11 adaptor is provided to comply with the older
610 Telstra wall socket. The 605 to RJ-11 adapter may be used
to convert the supplied RJ-11 cable, if the older connection is
required.
