NetComm NP720

Wireless Access Point

Specifically designed for office, business and commercial environments, the

NetComm NP720

Wireless Access Point offers advanced security features including WEP, WPA and WPA2
encryption, 802.1x support, and Radius-based MAC authentication.

SNMP support, Syslog support, and an easy-to-use Web-based GUI make network administration
a breeze. For complex Wireless networks, support for Client/Repeater mode and Bridge mode is
also included, as well as support for the 802.1Q VLAN standard.

Perfect for use with a “Hotspot” or other public access environment, the NP720 includes multiple
SSID support, SSID isolation, multiple security profiles, and UAM (Universal Access Method) support.

NetComm’s NP720 Wireless Access Point is one of a range of customisable solutions for your
WLAN and LAN environment.

KEY FEATURES

Easy configuration using web-based GUI or included software utility

108Mbps 802.11b/g Indoor Wireless Access Point

High quality robust material

2dBi detachable antenna

Power over Ethernet (PoE)

WEP, WPA-PSK, WPA2-PSK, 802.1X wireless security

AP, Repeater/Client AP, Point-to-Point (PTP), Point-to-Multipoint (PTMP) Modes

Multiple SSID, VLAN, Access Control

TECHNICAL SPECIFICATIONS

HARdWARE SPECIFICATIONS

LAN Port: 10/100 Base-T (RJ45), Auto-MDIX, IEEE802.3af PoE

LED: 1xStatus, 1xPower, 1xLAN, 1xWLAN

Console Port: 1 x DB9 female RS232

Dimensions: 141mm(L) x 100mm(W) x 27mm(H)

Regulatory Approvals: WiFi Pre-Certified, CE Class B, FCC Class B, WPA compliance

Power: DC 24V/500mA

SECURITY SPECIFICATIONS

WEP, WPA-PSK, WPA2-PSK, 802.1X wireless security

EAP-MD5, EAP-TLS, EAP-TTLS, PEAP

Radius-based MAC address authentication, MAC address Filter UAM (Universal

Access Method)

Client to client communication prevention per ESSID, Wireless Separation https,

Configurable Web Port

WIRELESS SPECIFICATIONS

IEEE 802.11b, IEEE 802.11g, IEEE 802.1X, IEEE 802.11d

AP, Repeater, Client AP, PTP, PTMP Multiple-SSID

Worldwide mode (802.11d), Roaming

1 x 2dbi detached antenna

Modulation Schemes: OFDM Symbol Modulation DQPSK, DQPSK, DBPSK, ROBO

Carrier Modulation

Channel: 11 Channels (US, Canada); 13 Channels (Europe); 14 Channels (Japan)

Coverage: Up to 465 square metres

Transmission Power: 18 dBm Maximum (user adjustable)

MANAgEMENT SPECIFICATIONS

Web browser management, Access Point Manager program, SNMP V1, V2C

Telnet & CLI management

Windows Utility to configure and manage multiple Access Points

Configuration file backup & restore

Detailed status reports (including System log and a list of all detected wireless

station), Statistics, syslog

OTHER FEATURES

Radius Accounting, VLAN

DHCP Client, WINS Client, Radius Client

Protocols: TCP/IP, NetBEUI, ARP, DHCP client, HTTP, NTP, RADIUS, WINS, Telnet,

FTP, HTTPs, SSL
