Newcon Optik NVS 6 User Manual

Page 23

Table 2-2 Before operation check (cont'd).

Step

Item

Procedure

NO-GO criteria

13 System

(cont'd)

Press the lock release button (see
Fig.2-2) and rotate the goggles to the
up and down positions. Make sure it
engages properly.
Check all adjustments: vertical, fore-
and–aft and tilt for proper operation.

Binocular will
not stay locked
in up or down
position. Lock–
release button is
missing.
Movement binds
or does not
adjusts.

Table 2-3 Operational checks.

14 System

Connect the power pack connector to
the mount connector. Install battery
cartridges filled with appropriate
batteries in both battery
compartments.
Place power switch in either ON
position. Look for green glow in
both eyepieces. Check the other ON
position.

CAUTION

Operate the NVS 6 only

under dark conditions.

Green glow
absent in one or
both eyepieces in
either switch
position.

Low
battery
indication

Place power switch in either ON
position and remove batteries (or just
pull the cartridge part away to break
contact) for that side, thereby the
low-battery indicator shall blink.

Indicator will not
blink.
