2. OPERATING INSTRUCTIONS
NOTE
The NVS 6 is a precision electro-optical instrument, so handle it
carefully. If the equipment fails to operate, refer to the
troubleshooting procedures in Chapter 3.
2.1 OPERATOR CONTROLS & ADJUSTMENTS
NVS 6 designed to adjust for differences in head shape and
corrects for most differences in eyesight. Fig.2-1 and Table 2.1
describe the controls and indicators.
Figure 2-1. Operator controls and adjustments
