National Instruments NI 9265 - Manual (Page 14)

NI 9265 Operating Instructions and Specifications 14 ni.com
Stability
Gain drift .................................... 30 ppm/°C
Offset drift .................................. 45 ppm/°C
External power supply
voltage range (V
sup
) .......................... 9–36 VDC
Protection (AO, V
sup
)
Overvoltage ................................ ±40 V
Short-circuit................................ Indefinitely
Update time
Noise ................................................. 600 nA
rms
Crosstalk ........................................... –90 dB
Number of
Channels
Update Time for R Series
Expansion Chassis
Update Time for
Any Other Chassis
One 3.5 μs 3 μs
Two 6.5 μs 5 μs
Three 9 μs 7.5 μs
Four 12
μs
9.5
μs
